1hp Overhead Monoblock Refrigeration Unit for Cold & Freezer Rooms 810x600x710mm | GLBYTCR10EL

The GLBYTCR10EL is a compact and powerful 1 HP monoblock refrigeration unit designed for both chilling and freezing cold room applications. Built for reliability, it offers a wide evaporation temperature range of -35°C to -5°C and operates efficiently in ambient conditions between -7°C and +43°C.

Equipped with a high-performance Sanyo inverter compressor (C-6RHZ125L9AAL), the unit delivers efficient cooling with a rated input power of 680W and a variable speed range of 30–80Hz. The unit is powered by a single-phase 220V supply, compatible with both 50Hz and 60Hz frequencies, ensuring flexibility across different electrical standards. Hot gas defrost ensures consistent performance, while high/low pressure switches provide dependable system protection.

The GLBYTCR10EL supports cold rooms up to 12m³ (chillers) and freezer rooms up to 7m³, making it ideal for restaurants, convenience stores, food storage facilities, and small commercial cold rooms. With a refrigeration capacity of up to 2000W at -5°C (ambient 32°C, 70Hz), it ensures strong cooling output across varied conditions.

Its compact overhead design allows for space-efficient installation, and the durable construction ensures long-term, continuous operation. The model is also compatible with CFRPANEL151522, CFRPANEL152122, CFRPANEL181822, CFRPANEL182422, and CFRPANEL212122 panels, ensuring seamless integration into cold room builds.

Key Features

• 1 HP monoblock refrigeration unit for chillers and freezers
• Power supply: Single phase 220V / 50Hz or 220V / 60Hz
• Rated input power: 680W
• Man run current: 8A
• Evaporation temperature range: -35°C to -5°C
• Ambient operating range: -7°C to +43°C
• Refrigerant: Eco-friendly R290
• Compressor: Sanyo inverter compressor (C-6RHZ125L9AAL)
• Speed range: 30–80Hz
• Refrigeration capacity: 690W at -35°C, 910W at -25°C, 1420W at -15°C, 2000W at -5°C
• Defrost system: Hot gas defrost
• Pressure control: High and low pressure switches for safe operation
• Fan motors: Condenser 120W (x1), Evaporator 80W (x1)
• External dimensions (WxDxH): 810 x 600 x 710 mm
• Net weight: 69 kg
• Applicable cold room volume: ≤12m³ (chiller, +2°C to +8°C)
• Applicable freezer room volume: ≤7m³ (-15°C to -18°C)
• Compact overhead design for easy installation
• Seamless compatibility with CFRPANEL cold room panels
• Ideal for restaurants, food shops, bakeries, and commercial storage

Please see under 'Specification' for detailed information.
